Reverse Tooth Cable Tie

Reverse-tooth nylon cable ties feature a unique external tooth design that effectively protects cables by preventing abrasion during bundling. Since the tie's serrations are positioned on the outside, the smooth surface of the tie makes direct contact with the cable or object, avoiding the surface damage issues that can occur with traditional internal-tooth ties. This makes it particularly suitable for bundling scenarios requiring delicate cable protection, such as automotive wiring harnesses, precision equipment, and electronics installations. These ties not only provide strong fastening but also ensure that the bundled object' s outer layer remains undamaged during use.

Material: Polyamide 6.6HS

Material Brand: /

Flammability of Raw Material: UL 94HB

Humidity Absorption: 2,7%-2,8% (23℃ -50% R.H.)

Installation Temperature: -20℃~+85℃

Working Temperature: -40℃~+105℃

Max Sustainable Temperature For Short Time: +120℃

Good resistance to bases, oils, greases, oil derivatives, chloriated solvents. Limited resistance to acids. Not resistant to phenols.

Carbon black addition gives a better UV resistance (only for Black Cabe Ties)

Performance and Advantages

External tooth design with a smooth inner surface

Bend design fits cable bundles, saving space

Low insertion force with high tensile strength

Complies with PA66 V0 standard

Can be bundled manually or with a tool gun for easy operation
